Model:CNME030502
Description:
CNME030502 Automatic Chemiluminescence Immunoassay System uses the magnetic microparticles based, Acridinium Ester(AE) direct chemiluminescence technology. The character of stable performance, fast report, convenient operation and reliable results could make it fully applicable to various application environments of medical laboratories.
The design orientation of CNME030502 could not only meet the routine test requirements of medium and small hospitals, but also provide supports to the assay development and STAT tests of large hospitals.
Features:
Fast
Single-module runs up to 180 T/H
Time to the first result:14 minutes
Convenient
Automatic startup and shutdown
Continuous reagents replacement and samples loading during the operation
STAT Prioritization, Automatic Rerun
Reliable
Full loaded unattended operation for 4 hours
Remote Diagnosis
Thorough system of metrological traceability
Stable
Multiple magnetic separation technology, high-efficient B/F separation.
Patented magnetic field design, minimize the magnetic beads' loss.
The track-based technology ensures the accurate sampling of micro-volume.
The needle has the detection function to the liquid level, clot and aspiration failure.
The carry-over is less than 0.1 ppm.
Specifications:
Performance | Technology: Automatic/single tube Principle: Acridinium
Ester (AE) Direct Chemiluminescence immunoassay technology
Throughput: 180 Tests/h for one module
Time to the first result: 14min |
Sample Module | Sample loading capacity:50,loading with sample racks.
Automatic retest, STAT samples could be placed randomly and tested preferentially |
Sample Loading
System Module | Sample carry-over <0.1ppm
Foam/Clot and Liquid level detection/Volume tracking/Collision-avoidance
Sample type: Serum /Plasma /Whole blood /Urine |
Reagent Module | 30 reagent positions
Information management through Radio Frequency
ldentification Card (RFID)
Real-time,onboard mixture of magnetic beads
Reagent online replacement |
Consumable Module | Loading capacity of cuvettes: 1200
Cuvettes loading by dumping |
Detection Module | Reaction temperature:37℃C
Mode:Compatible with the common immunoreaction
Mixing: Non-contact Stir
Magnetic separation: Multiple magnetic separation technology |
Function | Operation system: Windows 7 and above
Display: LCD touch screen
Remote diagnosis system
Automatic startup & shutdown
Bi-directional communication |
