Model:CNME0101VET-1
Features:
12.1 inch large-sized screen, anti-dazzle with 4°incline.
Wide-angle alarms indicator makes patients safer.
Unique designed LOGO for veterinary use only.
Variety of accessories for different size veterinaries.
Widely used in pet hospitals and animal clinics etc.
Large pulse rate range of 20-350 for maximum applications.
Selectable for 3 or 5 leads ECG mode.
3 NIBP cuffs are included and fit a variety of patients.
3-level visual/audio alarms and alarm events can be stored and reviewed.
Support slot interfaces:Network,Wi-fi.
Specifications:
| SpO2 | |
| Aturation range | 1% to 100% |
| Accuracy | 70-100%(±2%),<70% undefined |
| Resolution | 1% |
| Display sweep speed | 10.00 mm/sec |
| Pulse Rate | |
| Aturation range | 25bpm to 350bpm |
| Accuracy | ±2bpm/±2% take maximum |
| Resolution | 1bpm |
| ECG | |
| Aturation range | 25bpm to 350bpm |
| Accuracy | ±2bpm/±2% take maximum |
| Resolution | 1bpm |
| Leads | I,II,III,V,aVR,aVL or aVL |
| Display gain | X1/4,X1/2,X1,X2,X4 |
| Display sweep speed | 6.25,12.5,25,50mm/sec |
| NIBP | |
| Method | Oscillometric |
| Aturation Range | 0-300mmHg |
| Accuracy | Based on ANSI/AAMI SP10:1992 and 2002 Standards |
| Measurement Time | 30-50s typical,180s maximum |
| AUTO Interval Times | 2,3,5,10,30 min,or 1,2h |
| RESP | |
| Aturation range | 0-130rpm |
| Accuracy | ±1 pm |
| Resolution | 1rpm |
| TEMP | |
| Aturation range | 0-50ºC |
| Accuracy | ±0.2ºC |
| Resolution | 0.1ºC |
