Model:CNME0101V5
Features:
*7" colored and bright, high definition (800 x480)TFT LCD screen.
*Parameters: SpO2, ECG, Heart Rate, NIBP, TEMP*2,RESP(Optional Sidestream ETCO2).
*Suitable for adult, pediatric and neonatal patients.
*72 hours graphic and tabular trends of all parameters.
*32 seconds full-disclosure waveform review.
*120 hour NIBP and Sp02 measurement data can be stored and recalled.
*Built-in large capacity(4400mAh) rechargeable Lithium battery.
*With Ethernet connectivity, support to connect to Patient Management System.
*Network Host interface.
Specifications:
| Enclosure | |
| Weight | 2.05kg(4.52lb), including 1 battery |
| Dimensions | 324mm*129mm*183mm |
| Screen size | 177.8mm(7in.), measured diagonally |
| Screen type | TFT LCD, white LED backlight,viewing cone of 60°and optimal viewing distance of 1.5 meter |
| Resolution | 800*480pixels |
| Categories | Patient status and system status |
| Priorities | Low, medium, and high |
| Notification | Audible and visual |
| Setting | Full storage, low battery and sensor off |
| Alarm volume level | 45 to 85decibels |
| Alarm system delay | <10seconds |
| Configuration | |
| Standard | SpO2+ECG+NIBP+RESP+TEMP |
| Optional | SpO2,SpO2+NIBP,SpO2+NIBP+ECG, SpO2+NIBP+TEMP, SpO2+ECG+NIBP+RESP+TEMP+EtCO2.etc. Lithium Battery, Trolley, Brace, Central monitoring system |
