Hospital Portable ICU Stackable Intravenous Infusion Pump
Model:CNME010501
Features:
Stacked track
3.5 inch large screen
Alarm light
Lock point
Anti-free flow button
Panel and touch screen
Specifications:
|
Display | 3.5 inch color touch screen |
Flow Rate Range | 0.1 -2000 ml/h
infusion flow rate increment:
0.1-99.99 ml/h,in steps of 0.01ml/h
100.0-999.9 ml/h,in steps of 0.1ml/h
1000-2000ml/h,in steps of 1ml/h |
IV set brands | Recognize all major brands including additional brands upon agreement. Build-in 5 brands,support user extending and calibration |
Bolus Rate Range | 0.1-2000ml/h |
Accuracy | ±5% |
Infusion mode | CNME010501:3 modes(Rate,Vol,weight)
CNME010501plus:7 modes(Rate,Vol,weight,Intermittent, Loading dose,sequence,and Ramping mode) |
VTBI | 0.1-9999.99ml |
Drug Library | No less than 2000 cases |
Occlusion alarm pressure | 11 levels |
KVO Rate | 0.1~5.0 ml/h, step value 0.01ml. |
Standby time | 00:01 to 99:59, increments per minute |
Day/night mode | Set the start time during the day and night, the sound and brightness during the corresponding time period |
Event log | more than 2000. classified by operation records, alarm
records, and infusion records. time stamped in real time |
Patient history log | No less than 2000 logs |
Interface | MINI USB |
Wireless | Wifi;Nurse call (optional) |
Alarm Type | Use battery, Door open, Occlusion,Almost done, Forget operation, Infusion completion,Low Battery,Battery exhausted, malfunction etc.
|
|
AC Power | 110V-240V,50/60Hz |
External DC Power | 12V |
Battery | Rechargeable lithium-ion: 10-15V, 2.5A |
Operating time:About 6 hours at 25ml/h |
|
Classification | Class I,CF |
Waterproof | IPX3 |
Dimension | 240*78*171 (W*H*D mm) |
Weight | Approx.2kg |
